ISE Sonos - Page 35

ise smart connect KNX Sonos
Configuration
Order No. 1-0001-002
Product Manual Page 35 (76)
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
15 (group 1)
115 (group 2)
215 (group 3)
315 (group 4)
415 (group 5)
Select playlist
Write
1 byte
5.010
C-W--
Rubric:
Playlist
Data type:
Meter pulse (0 to 255)
Function:
Group 1/2/3/4/5 – Plays the selected playlist
Description:
Starts playback of the selected playlist.
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
16 (group 1)
116 (group 2)
216 (group 3)
316 (group 4)
416 (group 5)
Current playlist
Read
1 byte
5.010
CR-T-
Rubric:
Playlist
Data type:
Meter pulse (0 to 255)
Function:
Group 1/2/3/4/5 – Number of the currently selected playlist
Description:
Supplies the slot of the current playlist. It is 0 if no playlist has been selected or
if the playlist used has not been saved. If a playlist is stored in multiple
locations, behaviour will be ambiguous.
2
Object
Name
Direction
Data width
DP type
Flags
(CRWTU)
17 (group 1)
117 (group 2)
217 (group 3)
317 (group 4)
417 (group 5)
Shuffle play
Write
1 bit
1.003
C-W--
Rubric:
Playback mode
Data type:
Enable
Function:
Group 1/2/3/4/5 – Plays titles within the current playlist randomly
Description:
Activates (1) or stops (0) the random playback of tracks in the current playlist
(shuffle mode). 1 = Random order, 0 = Order of the playlist
2
A source is assigned to a fixed slot using the website of the ise smart connect KNX Sonos. The same source is assigned to multiple loca-
tions in a master-slave group. The Sonos device only transmits the source name which cannot be assigned to a unique slot. For this reason,
a source should only be assigned to one slot per master-slave group.
