Configuration
Order No. 1-0001-002
Product Manual Page 24 (76)
6 Configuration
Configuration of the ise smart connect KNX Sonos is divided into the following steps:
Preparations:
For explana-
tions, see
1 Mount device, connect it to KNX bus connection and auxiliary voltage.
 Chapter 5
2 Connect Sonos system to data network
and set up using software supplied with the Sonos components.
 Sonos
documentation
3 Install the ise smart connect KNX Sonos on the same IP network as the Sonos
components and make settings in the router of the IP network if necessary.
Configuration via ETS:
After installing the device and connecting the bus, power supply and Ethernet, the device can be com-
missioned. The preparatory configuration is carried out using the Engineering Tool Software, ETS,
available from the KNX Association, see www.knx.org.
1 Create the ise smart connect KNX Sonos as a device in the ETS.
 Section 6.1
2 Assign physical address as usual corresponding to the KNX topology.
3 Set IP address, IP subnet mask and standard gateway address of the ise
smart connect KNX Sonos or select "Obtain IP address automatically (from a
DHCP server)."
 Section 6.3
4 General parameters for setting the ise smart connect KNX Sonos.
 Section 6.4.1
5 Setting "IP addresses" parameter:
In this step, you inform the ise smart connect KNX Sonos of the IP addresses
of the Sonos devices to be addressed or select the "Auto Detect" setting.
 Section 6.4.2
6 Connect group addresses to group objects as usual.
 Section 6.5
10 The ise smart connect KNX Sonos is now ready for commissioning
via "Program ETS" and for testing of the functions.
