ITC VA-6000 Series User Manual

Digital Network Public Address & Voice Alarm System
- 20 -
5.2.4.Technical Specifications
Electric Index
AC power
Voltage
~220-240V/50-60Hz
Fuse specification
250V/0.5A, the slow type
DC power
Voltage
24V DC, ±20%
The maximum current
Less than 0.2A
Power consumption
5W
Performance index
Unbalanced signal input
THD
Rated output power),1KHz
Sensitivity
385mV
Impedance
10KΩ
Touch input
Relay programmable output
Short circuit, no voltage
Cooling mode
N/A
Protection
Over-current
Mechanical specifications
Dimension (L*W*D)
484* 44*447mm (19 inch width,1U)
Weight
About 2.5Kg
Installation
On desktop or in 19inch Rack
Color
Black
Environmental Requirement
Operating Temperature
+5℃~+40℃
Storage Temperature
-20℃~+70℃
Relative Temperature
No condensation
