ITC VA-6000 Series - 5.7.4 Technical Specification

Digital Network Public Address & Voice Alarm System
- 35 -
8. DC 24V input( when transition distance over 50m, need to add extra DC 24V power supply.
9. Device power switcher.
5.7.4.Technical specification
Electric index
DC
Voltage
24V DC, ±20%
Max current
0.1 A (including extension panel)
Power consumption
2.4W(including extension panel)
Performance index
Balanced signal output
Distortion
<1%, 1KHz rated power
Frequency response
80Hz~16KHz
Sensitivity
500mV
Impedance
10KΩ
SNR
>70dB
Line input
Distortion
<1%, 1KHz rated power
Frequency response
80Hz~16KHz
Sensitivity
350mV
Impedance
10KΩ
SNR
>70dB
Microphone
Sensitivity
5mV
Impedance
600Ω
Mechanical index
size
256×52×149mm
Net weight
About 1Kg
Installation
Desktop or 19 inch rack
Color
Black
Environmental requirement
Operating temperature
+5℃ ~ +40℃
Storage temperature
-20℃ ~ +70℃
Relative humidity
<95% (no condensation)
