Digital Network Public Address & Voice Alarm System
Online Interfaces on Host Rear Panel
Instruction:
Trigger Mode: There are two options in software (system default mode is short circuit mode):
1) Electric Level Mode--Intelligently detect physical connection status: open, short, normal or triggered.
2) Short Circuit Mode—Just detect input-voltage: triggered and normal.
Emergency Output: when the fire breaks out and actives fire alarm, the relay will close.
System Status Output: when there is any fault, the relay will open and cannot close manually.
DC 24VOutput (<1A): controled by software, can be started manually.
Note:
If current system doesn’t equip this device (some devices in system is optional), the corresponding icon
shows in grey and inoperable.
After entering “Host Status Main Menu” by pressing , press
to check working status of current host voice messages and files total in SD card (Note: EVAC and
prompt voice can only be checked in this way). BGM also can be checked by pressing in Main
Menu to enter BGM control interface, then it will show BGM working status.
6.2.View Working Status of Device Physical Zone
View working status of VA-6000MS (8 main/1 spare amplifier switcher):
In Main Menu, press amplifier controller to view submenu:
Main Menu Amplifier Controller Menu
To Next Page
