System-Related Functions
Copyright ©ITECH Electronic Co., Ltd. 118
between three units.
4. Power on the three instruments separately.
After the instrument is restarted, the screen shows that the instrument is
working in single mode.
Connect the instruments (Cabinet model)
⚫ Before connecting the system bus, you must ensure that each instrument is
in single mode (Single).
⚫ Fiber optic cables cannot be flexed or folded. When the cable is too long
and needs to be arranged, gently wrap the cable in a circle and gently tie it.
⚫ Before connecting the cables, ensure that the instrument power switch is off
and the main switch of the AC power input (distribution box) is off.
⚫ Before connecting 3 single instruments to the AC distribution box, ensure
that the distribution box capacity is sufficient. Refer to the corresponding
specifications for the AC input parameters of a single instrument.
For cabinet models, the same model can be connected in parallel. Taking two
15U instruments (with operation panel) as an example, the steps for parallel
operation are as follows.
1. Ensure that the power switches of the instrument and the main switch of the
AC power distribution box are off.
Refer wiring connection diagram to connect two units.
The configuration method is the same as 3U model instrument.
