ITW Alpine ALS 4.0 XE User Manual

6
ALS 4.0 XE
PRODUCT MANUAL
EN
1.2 General Specications
1.2.1 Machine Capacity
 Lumber Size Range
Min Max
Width 2.38” (64mm) 14” (355mm)
Thickness 1.38” (35mm) 1.77” (45mm)
Length 6” (152mm) 24’ (without additional support)
 Cut Types:
• Chords
• Webs
• Scissor bottom chords
• Wedges
• Sliders
• Single and double beveled ends
(if saw is equipped with optional bevel axis)
• Ripped valley bottom chords
(if saw is equipped with optional bevel axis)
• Floor truss webs
(if saw is equipped with optional bevel axis)
 Pieces:
• Minimum: 1” (25mm) for all pieces with four angle cuts
• Maximum Recommended Scarf: 104 inches at 8 degrees
