ITW Alpine ALS 4.0 XE User Manual

5
ALS 4.0 XE
PRODUCT MANUAL
EN
• Power Cable, LXM 52, 32.80ft 41043
(Used in L1P Axis)
• Feed Back Cable LXM52,16.4 ft 39177
(Used in L1, L2, T, Z Axes)
• Feed Back Cable LXM52, 19.68 ft 41036
(Used in A Axis)
• Feed Back Cable LXM52, 22.96 ft 37245
(Used in B Axis)
• Feed Back Cable LXM52, 32.8 ft 41043
(Used in L1P Axis)
 Quick Reference:
• Computer 38162
• Belt B1& A1 28979
• Small parts VFD 41069
• Safety Sticker Set 35194
All parts can be conveniently ordered from
our website. Visit: shop.alpineitw.com
Or email your order to Order@Alpineitw.com
1. Introduction
1.1 Parts List
 Suggested Stocking Parts:
• Emitter 23141
• Receiver 24679
• Door Switch 38207
• Door Switch Key 38208
• Module E-Stop 25990
• Lumber Present Sensor (Infeed) 24664
• Lumber Present Sensor (Printer) 20661
• SMC Valves Solenoid 36758
 Common Wear Parts:
• Belt L1 & L2 29107
• Blade Kit 35127
Includes: Blade
Screws
Nyloc Nuts
Torx Bit
 Motion Control Components:
• Servo Drive 3/12 amp #APN 37288
(Used in T Axis)
• Servo Drive 6/18 amp #APN 41075
(Used in A, B & L1P Axis)
• Servo Drive 10/30 amp #APN 41068
(Used in L1, L2 & Z Axis)
• Servo Motor 1.78 amp #APN 41010
(Used in T Axis)
• Servo Motor 3.91 amp without brake #41009
(Used in A ,B & L1P Axis)
• Servo Motor 3.91 amp with brake #41023
(Used in Z Axis)
• Servo Motor 7.69 amp #41020
(Used in L1 & L2)
• Blade Motor Mitsubishi #41027
• Blade Motor Drive Mitsubishi #41032
• Blade Motor Power Cable Mitsubishi 38471 Blade
• Motor Feedback Cable Mitsubishi 38472 Power
• Cable,Low Shield LXM 52 16.4ft 41037
(Used in T & Z Axis)
• Power Cable,LXM 52,16.4 ft 41039
(Used in L1 & L2)
• Power Cable,LXM 52,19.68ft 41040
(Used in A Axis)
• Power Cable,LXM 52, 22.96ft 41041
(Used in B Axis)
Throughout this manual, references
are made to contact Alpine Equipment
Customer Service. They can be reached at
800-521-9790 with any questions.
Disclaimer
The information contained in this document is believed to be accurate in all
respects but is not warranted by Alpine. The information is subject to change
without notice and should not be construed in any way as a commitment by
Alpine. Alpine assumes no responsibility for any errors or omissions in this
document. Every reasonable eort is made to keep this document current, but
in the event of discrepancy, Alpine engineering documentation, installation
and service and safety procedures shall prevail.
Copyright ©2021 by Alpine, a division of ITW Building Components Group Inc.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system,
or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written consent of
the publisher.
