Section C - Electrics
Circuit Schematic
Main Components
C-5 C-5
9803/9390-2
Circuit Schematic
Main Components
For Schematic Diagram K Fig 1. ( T C-7)
Table 1. Key to Schematic Diagram
1 Battery
2 Glowplug Common Rail
3 Primary Fuses
4 Starter Motor
5 Starter Solenoid
6 Neutral Start Relay
7 Neutral Switch
8 Starter Switch
9 E.S.O.S.
10 Alternator
11 Water Temp Switch
12 Engine Oil Press Switch
13 Instrument Panel
14 Fuel Sender
15 Instrument Console
a Buzzer
b High Coolant Temperature
c Low Engine Oil Pressure
d Not Used
e Excitation
f Alternator Charge
g Hourmeter
h Fuel Gauge
j Backlighting
k Parkbrake
l Differential Lock
m Glow Plug Indicator Repeater
n Trailer Indicator
16 Parkbrake Switch
17 Differential Lock Switch
18 Reverse Alarm
19 Auxiliary Power Supply Socket
20 Main Lighting Switch
21 LH Front Light
22 RH Front Light
23 Horn Switch
24 Front Horn
25 Beacon (option)
26 Beacon Switch (option)
27 Fan Control Relay
28 Fan Relay
29 Fan Temperature Switch
30 Fan Motor
31 Tipper Relay A (option)
32 Tipper Switch (option)
33 Tipper Relay B (option)
34 Tipper Motor (option)
35 Earth Terminal
36 Not Used
37 Deluxe Lighting Kit (option) Comprising
items 38 - 79
38 Ignition Relay 1
39 Brake Light Switch
40 Brake Light Relay
41 LH Brake Light
42 RH Brake Light
43 LH Trailer Brake Light
44 RH Trailer Brake Light
45 Hazard Switch
46 Flasher Unit
47 Hazard Switch Illumination
48
Indicator Switch Illumination
49 LH Trailer Rear Indicator
50 LH Front Indicator
51 LH Rear Indicator
52 Indicator Switch
