Section B - Body and Framework
B-9 B-9
9803/9390-2
Fuel Tank
Removal and Replacement
Fig 1. Fuel Tank and Sender Unit
A Fuel Tank D Filler Cap
B Fuel Gauge Sender Unit E Hose Clips
C Filler Neck F Hand Pump
