jcb Groundhog 6x4 - Differential Lock; Operation

Section D - Controls
Transmission Controls
Differential Lock
D-2 D-2
9803/9390-2
Differential Lock
Operation
The selector is connected via a cable to a lever arm on the
transaxle L.
Fig 2.
1 Knob (Hand Lever) 6 Cable
2 Lever Diff-lock Bar 7 Washer
3 Linkage 8 Circlip
4 Bushes
9
(1)
Washer
5
Pivot Bar
(1)
(1) Shared with Forward-Reverse Lever installation.
10
(1)
Nut
2
4
9
10
4
5
4
3
6
6
L
4
7
8
1
C025450
