Section B - Body and Framework
B-5 B-5
9803/9390-2
Cooling Pack and System
General Description
Fig 1.
1 Mounting Bracket - Upper 7 Top Hose
2 Rubber Grommets 8 Bottom Hose
3 Radiator 9 Vent Overflow Tube
4 Electric Fan Connector 10 Filler Bottle
5 Temperature Switch (Fan) 11 Pressure Cap
6 Connection - Vent Tube
C025470
5
4
3
2
2
6
1
11
10
F
R
9
8
7
R Return Flow from Thermostat (Engine)
F Flow to Water Pump (Engine)
