jcb Groundhog 6x4 - Forward - Reverse Selector; Operation; Transmission Controls

Section D - Controls
D-1 D-1
9803/9390-2
Transmission Controls
Forward - Reverse Selector
Operation
Mechanical linkages connect the selector lever to the
transaxle shift arm 9. Note the location of the Neutral Start
switch S.
Fig 1.
1 Knob (Lever) 6 Clevis Pin
2 Selector Lever 7 Clevis Clip
3 Lever Arm 8 Gear Linkage
4 Bushes 9 Shift Arm (Transaxle)
5 Return Spring
8
8
S
6
7
4
3
2
1
5
9
9
C025440
