Section B - Body and Framework
General Description
Overview
B-2 B-2
9803/9390-2
The space frame steel chassis houses the engine and
transmission system at the rear of the vehicle, beneath the
load bay.
The body panels are moulded plastic construction. They
are removable to provide access.
The ROPS is a safety protection frame of steel
construction.
Fig 2.
01
0
I
II
III
G
H
F
E
