Section B - Body and Framework
B-1 B-1
9803/9390-2
General Description
Overview
Fig 1.
Also see K Fig 2. ( T B-2)
A
M
J
D
B
C
G
C
K
L
A Front End Panel G Fascia Panel
B Wheel Fenders H Switch Panel
C
(1)
(1) Steel or Moulded Plastic load bay (option)
Load Bay J Roll Over Protection Structure (ROPS) - option
D Side Panel (Fuel Filler) K Engine Bay Rear Access Grille
E Side Panel (Radiator Grille) L Lights (Rear)
F Centre Console M Operators Manual Stowage Compartment
