Section H - Steering
H-9 H-9
9803/9390-2
Kingpins
Removal and Replacement
Fig 1. Sectional View of Steering Swivel (Kingpin)
A
(1)
Kingpin Body F Thrust Washer (2-off)
B Swivel Boss (Part of Suspension Arm)
G
(2)
Pivot Bolt
C Grease Nipple (Within Swivel Boss)
H
(3)
Washers (Hardened)
D Bush (2-off)
J
(2)
Nut (Self-locking)
E Pivot Pin
(1) The kingpins are handed - left and right sides.
(2) Grade 12.9 (Nut grade equivalent to bolt).
(3) Hardened washers - NOT ordinary washers. Using incorrect specification items could result in a reduction of clamping
efficiency. Use correct grade JCB hardened washers.
G
H
F
F
C
E
H
J
A
A
A
B
B
D
F
D
D
