CONTROL SYSTEM
6-48
TC-15001-rev.3
(2) Run the connecting cable into the metal
conduit.
(3) Lead the connecting cable through the
NQRFNRXWKROH
 6HFXUHWKHEUDFNHW
 $WWDFKWKH,5UHFHLYHUNLW
'RQRWSLQFKWKHFDEOHEHWZHHQWKHEUDFNHWDQGWKH,5UHFHLYHUNLWFRYHUZKHQDWWDFKLQJWKH,5
UHFHLYHUNLW$WWDFKWKH,5UHFHLYHUNLWFRYHUIROORZLQJWKHVHGLUHFWLRQV
(2) Select the connecting cable outlet direction
DQGFXWRXWRQHRIWKHNQRFNRXWKROHVRQ
the cover.
< Situation A > < Situation B >
Cover
Connecting
Cable
Mounting Bracket
Cover
Hook the left side
of the cover to the
mounting bracket.
Push the right side
of the cover onto
the bracket.
Click sound is heard
when the cover is
completely hooked
onto the bracket.
Connecting
Cable
The connecting cable should
not be exposed. Lead it through
the metal conduit in the wall.
Connecting Cable
Securing Screw
(M4, Field-Supplied)
Mounting Bracket
Click sound is heard
when the cover is
completely hooked
onto the bracket.
Cover
Hook the left side of
the cover to the mounting
bracket. Push the right
side of the cover onto
the bracket.
Do not loosen the connecting
cable for the IR receiver kit.
Otherwise, it may become
pinched between the two
components causing a
malfunction of the indoor unit.
Select the connecting
cable outlet direction
and cut out of the
knock-out holes ( ).
Secure the tabs of the cover
into the slots on the left side
of the bracket.
