6.9.9 Use of Memory Card
Use a memory card to write setting data to the memory card.
1. Unlock the write protection lock of the memory card.
1. Push the memory card (a) down until you hear the “click” .
The card is released and can be removed.
2. Close the lid (b).
Write Protection Lock Switch
When this switch is locked,
data cannot be written onto
the memory card.
Slide the switch in the
direction of the arrow.
Lid
Lid
2.Open cover/lid (a). Then insert memory card(b).
(a)
(b)
(b)
(a)
Usable Memory card
SD memory cards or SDHC memory cards based on the SD Standard are
acceptable However, some cards may not operate properly.
Ɣ7KHVHPHPRU\FDUGVDUHFRQVLGHUHGDFFHSWDEOHE\-RKQVRQ&RQWUROV
-
SanDisk Ultra SD
TM
/SDHC
TM
card
-
SanDisk SD
TM
/SDHC
TM
card (standard type)
Folders and Files
Memory Card
CS-EZ………Required folder to use the memory card in this controller.
Sub Folder……Up to 50 folders can be displayed.
Setting Data File………
Setting Data File………
Up to 50 files can be displayed for each folder.
Name of the file (New File)
SettingData_20120401080040.ezd
Year Month Day Hour Min Sec
Ɣ If unavailable characters are included in the name, the character will be replaced by “?”.
,QWKDWFDVHWKH¿OHRUIROGHUPD\QRWEHDFFHVVLEOH
Ɣ (QWHUWKHQDPHRIWKHVXEIROGHURUWKH¿OHZLWKLQFKDUDFWHUV)LOHQDPHVDUHOLPLWHGWR
characters.
Ɣ )LOHVHWWLQJGDWDLVVDYHGDVD³H]G´¿OH7KHUHLVQRQHHGWRLQFOXGH³H]G´LQWKHFKDUDFWHUV
Ɣ :KHQWKHQXPEHURI¿OHVLQHDFKVXEIROGHUH[FHHGDZDUQLQJPHVVDJHZLOOEHGLVSOD\HGDQG
the screen will return to the Memory Card menu.
Insert the memory card Remove the memory card
Ŷ,QVHUWWKHPHPRU\FDUG Ŷ5HPRYHWKHPHPRU\FDUG
