Johnson Controls York YKEP Series User Manual

FORM 160.77-O2
ISSUE DATE: 11/15/2011
JOHNSON CONTROLS
102
SECTION 4 - MODBUS RTU SLOT LIST
Modbus DF1 Count Logix Tag Description
10332 N12:14/8 232 AI_ZE100B.AL SECONDARY PRV POSITION LOW
10333 N12:14/9 233 AI_ZE100B.ALL SECONDARY PRV POSITION VERY LOW
10334 N12:14/10 234 AI_ZE100B.AH SECONDARY PRV POSITION HIGH
10335 N12:14/11 235 AI_ZE100B.AHH SECONDARY PRV POSITION VERY HIGH
10336 N12:14/12 236 AI_ZE142A.OOR PRIMARY THRUST PROX PROBE OUT OF RANGE
10337 N12:14/13 237 AI_ZE142A.AL PRIMARY THRUST PROX PROBE LOW
10338 N12:14/14 238 AI_ZE142A.ALL PRIMARY THRUST PROX PROBE VERY LOW
10339 N12:14/15 239 AI_ZE142A.AH PRIMARY THRUST PROX PROBE HIGH
10340 N12:15/0 240 AI_ZE142A.AHH PRIMARY THRUST PROX PROBE VERY HIGH
10341 N12:15/1 241 AI_ZE149A.OOR PRIMARY VGD POSITION OUT OF RANGE
10342 N12:15/2 242 AI_ZE149A.AL PRIMARY VGD POSITION LOW
10343 N12:15/3 243 AI_ZE149A.ALL PRIMARY VGD POSITION VERY LOW
10344 N12:15/4 244 AI_ZE149A.AH PRIMARY VGD POSITION HIGH
10345 N12:15/5 245 AI_ZE149A.AHH PRIMARY VGD POSITION VERY HIGH
10346 N12:15/6 246 AI_ZE149B.OOR SECONDARY VGD POSITION OUT OF RANGE
10347 N12:15/7 247 AI_ZE149B.AL SECONDARY VGD POSITION LOW
10348 N12:15/8 248 AI_ZE149B.ALL SECONDARY VGD POSITION VERY LOW
10349 N12:15/9 249 AI_ZE149B.AH SECONDARY VGD POSITION HIGH
10350 N12:15/10 250 AI_ZE149B.AHH SECONDARY VGD POSITION VERY HIGH
10351 N12:15/11 251 ZC_142A.Prox_AL PRIMARY COMPRESSOR THRUST REVERSE ALARM
10352 N12:15/12 252 ZC_142A.Prox_ALL PRIMARY COMPRESSOR THRUST REVERSE TRIP
10353 N12:15/13 253 ZC_142A.Prox_AH PRIMARY COMPRESSOR THRUST FORWARD ALARM
10354 N12:15/14 254 ZC_142A.Prox_AHH PRIMARY COMPRESSOR THRUST FORWARD TRIP
10355 N12:15/15 255 ZC_142A.Uncalibrated PRIMARY COMPRESSOR THRUST UNCALIBRATED
10356 N12:16/0 256 ZC_142A.Trip_Prox PRIMARY COMPRESSOR THRUST TRIP (CALL FAC-
TORY SERVICE)
10357 N12:16/1 257 ZC_142A_ProxCalActive PRIMARY COMPRESSOR PROXIMITOR CALIBRA-
TION ACTIVE
10358 N12:16/2 258 ZC_142A_CalOutofRange PRIMARY COMPRESSOR PROXIMITOR CALIBRA-
TION OUT OF RANGE
10359 N12:16/3 259 YPWMP_HS_PRV.Cal_
Complete
HS PRV CALIBRATION COMPLETED
10360 N12:16/4 260 YPWMP_HS_VGD.
Cal_Active
HS VGD CALIBRATION STARTED
10361 N12:16/5 261 YPWMP_LS_PRV.Cal_
Active
LS PRV CALIBRATION STARTED
10362 N12:16/6 262 YPWMP_HS_VGD.Cal_
Complete
HS VGD CALIBRATION COMPLETED
10363 N12:16/7 263 YPWMP_LS_PRV.Cal_
Complete
LS PRV CALIBRATION COMPLETED
10364 N12:16/8 264 YPWMP_LS_VGD.Cal_
Active
LS VGD CALIBRATION STARTED
10365 N12:16/9 265 YPWMP_LS_VGD.Cal_
Complete
LS VGD CALIBRATION COMPLETED
10366 N12:16/10 266 YPWMP_HS_PRV.Cal_
Active
HS PRV CALIBRATION STARTED
10367 N12:16/11 267 ALARM SPARE W17 B11
