Johnson Controls York YKEP Series User Manual

FORM 160.77-O2
ISSUE DATE: 11/15/2011
SECTION 4 - MODBUS RTU SLOT LIST
JOHNSON CONTROLS
101
4
Modbus DF1 Count Logix Tag Description
10287 N12:11/11 187 AI_TE103.AL LEAVING CONDENSER LIQUID TEMP LOW
10288 N12:11/12 188 AI_TE103.ALL LEAVING CONDENSER LIQUID TEMP VERY LOW
10289 N12:11/13 189 AI_TE103.AH LEAVING CONDENSER LIQUID TEMP HIGH
10290 N12:11/14 190 AI_TE103.AHH LEAVING CONDENSER LIQUID TEMP VERY HIGH
10291 N12:11/15 191 AI_TE111.OOR EVAPORATOR REFRIGERANT TEMP OUT OF RANGE
10292 N12:12/0 192 AI_TE111.AL EVAPORATOR REFRIGERANT TEMP LOW
10293 N12:12/1 193 AI_TE111.ALL EVAPORATOR REFRIGERANT TEMP VERY LOW
10294 N12:12/2 194 AI_TE111.AH EVAPORATOR REFRIGERANT TEMP HIGH
10295 N12:12/3 195 AI_TE111.AHH EVAPORATOR REFRIGERANT TEMP VERY HIGH
10296 N12:12/4 196 AI_TE112.OOR PRIMARY DISCHARGE TEMP OUT OF RANGE
10297 N12:12/5 197 AI_TE112.AL PRIMARY DISCHARGE TEMP LOW
10298 N12:12/6 198 AI_TE112.ALL PRIMARY DISCHARGE TEMP VERY LOW
10299 N12:12/7 199 AI_TE112.AH PRIMARY DISCHARGE TEMP HIGH
10300 N12:12/8 200 AI_TE112.AHH PRIMARY DISCHARGE TEMP VERY HIGH
10301 N12:12/9 201 AI_TE113.OOR SECONDARY DISCHARGE TEMP OUT OF RANGE
10302 N12:12/10 202 AI_TE113.AL SECONDARY DISCHARGE TEMP LOW
10303 N12:12/11 203 AI_TE113.ALL SECONDARY DISCHARGE TEMP VERY LOW
10304 N12:12/12 204 AI_TE113.AH SECONDARY DISCHARGE TEMP HIGH
10305 N12:12/13 205 AI_TE113.AHH SECONDARY DISCHARGE TEMP VERY HIGH
10306 N12:12/14 206 AI_TE114.OOR SUBCOOLER DROPLEG TEMP OUT OF RANGE
10307 N12:12/15 207 AI_TE114.AL SUBCOOLER DROPLEG TEMP LOW
10308 N12:13/0 208 AI_TE114.ALL SUBCOOLER DROPLEG TEMP VERY LOW
10309 N12:13/1 209 AI_TE114.AH SUBCOOLER DROPLEG TEMP HIGH
10310 N12:13/2 210 AI_TE114.AHH SUBCOOLER DROPLEG TEMP VERY HIGH
10311 N12:13/3 211 AI_TE140.OOR OIL SUMP TEMP OUT OF RANGE
10312 N12:13/4 212 AI_TE140.AL OIL SUMP TEMP LOW
10313 N12:13/5 213 AI_TE140.ALL OIL SUMP TEMP VERY LOW
10314 N12:13/6 214 AI_TE140.AH OIL SUMP TEMP HIGH
10315 N12:13/7 215 AI_TE140.AHH OIL SUMP TEMP VERY HIGH
10316 N12:13/8 216 AI_XE149A.OOR PRIMARY STALL NOISE OUT OF RANGE
10317 N12:13/9 217 AI_XE149A.AL PRIMARY STALL NOISE LOW
10318 N12:13/10 218 AI_XE149A.ALL PRIMARY STALL NOISE VERY LOW
10319 N12:13/11 219 AI_XE149A.AH PRIMARY STALL NOISE HIGH
10320 N12:13/12 220 AI_XE149A.AHH PRIMARY STALL NOISE VERY HIGH
10321 N12:13/13 221 AI_XE149B.OOR SECONDARY STALL NOISE OUT OF RANGE
10322 N12:13/14 222 AI_XE149B.AL SECONDARY STALL NOISE LOW
10323 N12:13/15 223 AI_XE149B.ALL SECONDARY STALL NOISE VERY LOW
10324 N12:14/0 224 AI_XE149B.AH SECONDARY STALL NOISE HIGH
10325 N12:14/1 225 AI_XE149B.AHH SECONDARY STALL NOISE VERY HIGH
10326 N12:14/2 226 AI_ZE100A.OOR PRIMARY PRV POSITION OUT OF RANGE
10327 N12:14/3 227 AI_ZE100A.AL PRIMARY PRV POSITION LOW
10328 N12:14/4 228 AI_ZE100A.ALL PRIMARY PRV POSITION VERY LOW
10329 N12:14/5 229 AI_ZE100A.AH PRIMARY PRV POSITION HIGH
10330 N12:14/6 230 AI_ZE100A.AHH PRIMARY PRV POSITION VERY HIGH
10331 N12:14/7 231 AI_ZE100B.OOR SECONDARY PRV POSITION OUT OF RANGE
