FORM 160.77-O2
ISSUE DATE: 11/15/2011
JOHNSON CONTROLS
93
44
Modbus DF1 Count Logix Tag Description
00001 N15:0/0 0 BAS_Commands.0 Remote Start Initiate
00002 N15:0/1 1 BAS_Commands.1 Remote Stop Initiate
00003 N15:0/2 2 BAS_Commands.2 Remote System Reset / Alarm Acknowledge
40001 N16:0 0 BAS_Setpoints[0 Remote Chilled Water Setpoint offset
40002 N16:1 1 BAS_Setpoints[1 reserved
40003 N16:2 2 BAS_Setpoints[2 Demand Limit Setpoint Percentage
40004 N16:3 3 BAS_Setpoints[3 Pulldown Demand Limit Setpoint Percentage
10001 N13:0/0 0 DI_EmergencyStop
10002 N13:0/1 1 DI_LSVaneMtrSw
10003 N13:0/2 2 DI_HSVaneMtrSw
10004 N13:0/3 3 DI_LSStarterFault
10005 N13:0/4 4 DI_HSStarterFault
10006 N13:0/5 5 DI_LSCompMTRInterlock
10007 N13:0/6 6 spare
10008 N13:0/7 7 DI_LS_VSDOilPumpFault
10009 N13:0/8 8 DI_HS_VSDOilPumpFault
10010 N13:0/9 9 DI_HSProxSwitch
10011 N13:0/10 10 DI_REMOTESTARTSTOP
10012 N13:0/11 11 DI_HardwireSafetyRelay
10013 N13:0/12 12 DI_LS_HighPressCutout
10014 N13:0/13 13 DI_HS_HighPressCutout
10015 N13:0/14 14 spare
10016 N13:0/15 15 spare
10017 N13:1/0 16 DO_OilHeater
10018 N13:1/1 17 DO_LSMtrStarter
10019 N13:1/2 18 DO_HSMtrStarter
10020 N13:1/3 19 DO_LSLiqLineSolVlv
10021 N13:1/4 20 DO_LSOilRtnSolVlv
10022 N13:1/5 21 DO_LS_OilPumpRun
10023 N13:1/6 22 DO_HS_OilPumpRun
10024 N13:1/7 23 DO_RemoteReadyToStart
10025 N13:1/8 24 spare
10026 N13:1/9 25 spare
10027 N13:1/10 26 spare
10028 N13:1/11 27 spare
10029 N13:1/12 28 spare
10030 N13:1/13 29 spare
10031 N13:1/14 30 spare
10032 N13:1/15 31 spare
10033 N13:2/0 32 DO_LSPRV_Open
10034 N13:2/1 33 DO_LSPRV_Close
10035 N13:2/2 34 DO_HSPRV_Open
TABLE 3 - MODBUS RTU SLOT LIST
SECTION 4 - MODBUS RTU SLOT LIST
