SECTION 4 - MODBUS RTU SLOT LIST
Modbus DF1 Count Logix Tag Description
10036 N13:2/3 35 DO_HSPRV_Close
10037 N13:2/4 36 DO_LSVGD_Open
10038 N13:2/5 37 DO_LSVGD_Close
10039 N13:2/6 38 DO_HSVGD_Open
10040 N13:2/7 39 DO_HSVGD_Close
10041 N13:2/8 40 spare
10042 N13:2/9 41 spare
10043 N13:2/10 42 spare
10044 N13:2/11 43 spare
10045 N13:2/12 44 spare
10046 N13:2/13 45 spare
10047 N13:2/14 46 spare
10048 N13:2/15 47 spare
10049 N13:3/0 48
10050 N13:3/1 49
10051 N13:3/2 50
10052 N13:3/3 51
10053 N13:3/4 52
10054 N13:3/5 53 DO_R1Reset
10055 N13:3/6 54
10056 N13:3/7 55
10057 N13:3/8 56 spare
10058 N13:3/9 57 spare
10059 N13:3/10 58 spare
10060 N13:3/11 59 B_ChilledFlow 1= Chilled Water Flow
10061 N13:3/12 60 B_CondFlow 1= Condenser Water Flow
10062 N13:3/13 61 B_LSCompMtrIntlk Primary motor Status 1=run
10063 N13:3/14 62 B_HSCompMtrIntlk Secondary / Economizer motor Status 1=run
10064 N13:3/15 63 IF_Units 0=English (PSI, ‘F) 1=Metric (BAR, ‘C)
30200 F10:0 0 AI_IT160A.Scaled PRIMARY Motor Current
30202 F10:1 1 AI_IT160B.Scaled ECONOMIZER MOTOR Current
30204 F10:2 2 AI_PE111.Scaled Evaporator Refrig. Pressure
30206 F10:3 3 AI_PE113.Scaled Condenser Refrig. Pressure
30208 F10:4 4 AI_PE116.Scaled Economizer Refrig. Pressure
30210 F10:5 5 AI_PE140.Scaled Compressor Sump Oil Pressure
30212 F10:6 6 spare 6
30214 F10:7 7 AI_PE141A.Scaled PRIMARY Compressor High Oil Pressure
30216 F10:8 8 AI_PE141B.Scaled ECONOMIZER COMPRESSOR High Oil Pressure
30218 F10:9 9 spare 9
30220 F10:10 10 spare 10
30222 F10:11 11 AI_LE114.Scaled Subcooler Refrig. Liquid Level
30224 F10:12 12 AI_LE116.Scaled Economizer Refrig. Liquid Level
30226 F10:13 13 ZC_142A.ProxDifferential PRI Comp SEC Thrust Bearing Probe Gap
30228 F10:14 14 C_LSKW+C_HSKW System Kilowatts
30230 F10:15 15 C_LSPRVPosition PRIMARY PRV Position
30232 F10:16 16 C_HSPRVPosition SECONDARY PRV Position
