Johnson Controls York YKEP Series User Manual

FORM 160.77-O2
ISSUE DATE: 11/15/2011
SECTION 4 - MODBUS RTU SLOT LIST
JOHNSON CONTROLS
95
4
Modbus DF1 Count Logix Tag Description
30234 F10:17 17 AI_RST100.Scaled Hardwired Remote Chilled Water Setpoint
30236 F10:18 18 AI_TE100.Scaled Chilled Water Out Temperature
30238 F10:19 19 AI_TE101.Scaled Chilled Water In Temperature
30240 F10:20 20 AI_TE103.Scaled Condenser Water Out Temperature
30242 F10:21 21 AI_TE102.Scaled Condenser Water In Temperature
30244 F10:22 22 AI_TE111.Scaled Evaporator Refrig. Liquid Temperature
30246 F10:23 23 AI_TE112.Scaled PRI Comp Refrig. Discharge Temperature
30248 F10:24 24 AI_TE113.Scaled SEC Comp Refrig. Discharge Temperature
30250 F10:25 25 AI_TE114.Scaled Subcooled Refrig. Liquid Temperature
30252 F10:26 26 AI_TE140.Scaled Compressor Oil Sump Temperature
30254 F10:27 27 CC_MtrCommandAsHz Primary Motor VSD speed in Hertz
30256 F10:28 28 AI_5VOLTSUPPLY.Scaled Five Volt Supply
30258 F10:29 29 AI_RST160.Scaled Hardwired Remote Demand Limit Setpoint
30260 F10:30 30 AI_PE149A.Scaled PRI VGD Pressure Sensor / Intermediate Pressure
30262 F10:31 31 AI_XE149A.Scaled PRI VGD Stall Noise Level
30264 F10:32 32 C_LS_VGDPosition PRI VGD Position
30266 F10:33 33 AI_PE149B.Scaled SEC VGD Pressure Sensor
30268 F10:34 34 AI_XE149B.Scaled SEC VGD Stall Noise Level
30270 F10:35 35 C_HS_VGDPosition SEC VGD Position
30272 F10:36 36 AO_TCV100C.Scaled Hot Gas Bypass Valve
30274 F10:37 37 AO_LCV114.Scaled Subcooler Variable Orice Valve
30276 F10:38 38 AO_LCV116.Scaled Economizer Variable Orice Valve
30278 F10:39 39 reserved reserved
30280 F10:40 40 PC_141A.Cv PRI Comp VS Oil Pump Drive Control
30282 F10:41 41 PC_141B.Cv SEC Comp VS Oil Pump Drive Control
30400 F11:0 0 C_SystemHead System Head (Cond Pres - Evap Pres)
30402 F11:1 1 C_EvapSmallTempDiff Evaporator Small Diff Temp
30404 F11:2 2 C_CondSmallTempDiff Condenser Small Diff Temp
30406 F11:3 3 PC_141B.Hz SEC VS Frequency
30408 F11:4 4 PC_141A.Hz PRI VS Frequency
30410 F11:5 5 C_CondenserSatTemp Condenser Saturated Liquid Temperature
30412 F11:6 6 C_EvapSatTemp Evaporator Saturated Liquid Temperature
30414 F11:7 7 C_EconomizerSatTemp Economizer Saturated Temperature
30416 F11:8 8 BAS_Calculated[8] PRI Discharge Superheat Temperature
30418 F11:9 9 BAS_Calculated[9] SEC Discharge Superheat Temperature
30420 F11:10 10 PC_141A.OilDiff SEC Oil Supply Pressure
30422 F11:11 11 PC_141B.OilDiff PRI Oil Supply Pressure
30424 F11:12 12 C_LS_MinimumFreq PRI Minimum Antisurge Frequency
30426 F11:13 13 C_HSComprHead SEC Compressor Head
30428 F11:14 14 CC_LSR1 LSR1
30430 F11:15 15 CC_LSR2 LSR2
30432 F11:16 16 CC_LSR3 LSR3
30434 F11:17 17 CC_LSR4 LSR4
30436 F11:18 18 CC_HSR1 HSR1
30438 F11:19 19 CC_HSR2 HSR2
30440 F11:20 20 CC_HSR3 HSR3
