Johnson Controls York YKEP Series User Manual

FORM 160.77-O2
ISSUE DATE: 11/15/2011
JOHNSON CONTROLS
3
CHANGEABILITY OF THIS DOCUMENT
In complying with Johnson Controls’ policy for con-
tinuous product improvement, the information con-
tained in this document is subject to change without
notice. Johnson Controls makes no commitment to
update or provide current information automatically to
the manual owner. Updated manuals, if applicable, can
be obtained by contacting the nearest Johnson Controls
Service office.
Operating/service personnel maintain responsibility for
the applicability of these documents to the equipment.
If there is any question regarding the applicability of
these documents, the technician should verify whether
the equipment has been modified and if current litera-
ture is available from the owner of the equipment prior
to performing any work on the chiller.
ASSOCIATED LITERATURE
NOMENCLATURE
MANUAL DESCRIPTION FORM NUMBER
YKEP Installation & Re-assembly 160.77-N1
YKEP Unit Operation & Maintenance 160.77-O1
YKEP Control Center Operation 160.77-O2
YKEP Unit & Control Panel Renewal Parts 160.77-RP1
YKEP Installation Checklist 160.77-CL1
YKEP Startup Checklist 160.77-CL2
YKEP Wiring Diagram - Field Connections 160.77-PW1
YKEP Wiring Diagram - Unit Wiring and Field Control Modication 160.77-PW2
Liquid Cooled Solid State Starter - Operation 160.00-O2
Medium Voltage Variable Speed Drive (2300v - 6600v) - Operation 160.00-O6
Medium Voltage Variable Speed Drive (10,000v - 13,800v) - Operation 160.00-O8
Unit Mounted Medium Voltage Solid State Starter (2300v - 4160v) - Operation 160.00-O7
Long-Term Storage Requirements - General 50.20-NM1
Long-Term Storage Requirements - Field Preparation 50.20-NM5
Long-Term Storage - Periodic Checklist and Logs 50.20-CL5
* For both Primary and Economizer power supply: “-” = 60Hz and “5” = 50Hz
Primary Motor
Primary Power Supply *
Economizer Compressor
Primary Compressor
Economizer Motor
Economizer Power Supply *
Condenser
Modification LevelEvaporator
Special FeaturesModel
YKEP BD B5 K7 Q3 DL CF5 A S
-
LD15116
