Johnson Controls York YKEP Series User Manual

FORM 160.77-O2
ISSUE DATE: 11/15/2011
SECTION 4 - MODBUS RTU SLOT LIST
JOHNSON CONTROLS
97
4
Modbus DF1 Count Logix Tag Description
10112 N12:0/12 12 ALARM SPARE W0 B12
10113 N12:0/13 13 ALARM SPARE W0 B13
10114 N12:0/14 14 ALARM SPARE W0 B14
10115 N12:0/15 15 ALARM SPARE W0 B15
10116 N12:1/0 16 ALARM SPARE W1 B0
10117 N12:1/1 17 ALARM SPARE W1 B1
10118 N12:1/2 18 ALARM SPARE W1 B2
10119 N12:1/3 19 ALARM SPARE W1 B3
10120 N12:1/4 20 ALARM SPARE W1 B4
10121 N12:1/5 21 ALARM SPARE W1 B5
10122 N12:1/6 22 ALARM SPARE W1 B6
10123 N12:1/7 23 ALARM SPARE W1 B7
10124 N12:1/8 24 ALARM SPARE W1 B8
10125 N12:1/9 25 ALARM SPARE W1 B9
10126 N12:1/10 26 ALARM SPARE W1 B10
10127 N12:1/11 27 ALARM SPARE W1 B11
10128 N12:1/12 28 ALARM SPARE W1 B12
10129 N12:1/13 29 ALARM SPARE W1 B13
10130 N12:1/14 30 ALARM SPARE W1 B14
10131 N12:1/15 31 ALARM SPARE W1 B15
10132 N12:2/0 32 TRIP_PowerFailure TRIP: POWER FAILURE
10133 N12:2/1 33 TRIP_ProgFault TRIP: PLC PROGRAM FAULT (REFER TO CODES)
10134 N12:2/2 34 TRIP_EmergencyStop EMERGENCY STOP
10135 N12:2/3 35 TRIP_LSMotorIntlk PRIMARY MOTOR STARTER INTERLOCK FAULT
10136 N12:2/4 36 TRIP_LS_ExcessStarts PRIMARY MOTOR EXCESS STARTS IN 24 HOUR
PERIOD
10137 N12:2/5 37 TRIP_LSStarterFault PRIMARY MOTOR STARTER FAULT CONTACT
10138 N12:2/6 38 TRIP_LS_HighPressCu-
tout
PRIMARY HIGH PRESSURE CUTOUT
10139 N12:2/7 39 TRIP_HS_HighPressCu-
tout
SECONDARY HIGH PRESSURE CUTOUT
10140 N12:2/8 40 TRIP_ChilledFlow LOW CHILLED WATER FLOW
10141 N12:2/9 41 TRIP_CondFlow LOW CONDENSER WATER FLOW
10142 N12:2/10 42 TRIP_LS_MotorLube TRIP: PRIMARY MOTOR LUBRICATION REQUIRED
10143 N12:2/11 43 ALARM SPARE W2 B11
10144 N12:2/12 44 ALARM SPARE W2 B12
10145 N12:2/13 45 ALARM SPARE W2 B13
10146 N12:2/14 46 ALARM SPARE W2 B14
10147 N12:2/15 47 ALARM SPARE W2 B15
10148 N12:3/0 48 TRIP_CommFlt_Slot1 TRIP: COMMUNICATIONS FAULT WITH SLOT 1
10149 N12:3/1 49 TRIP_CommFlt_Slot2 TRIP: COMMUNICATIONS FAULT WITH SLOT 2
10150 N12:3/2 50 TRIP_CommFlt_Slot3 TRIP: COMMUNICATIONS FAULT WITH SLOT 3
10151 N12:3/3 51 TRIP_CommFlt_Slot4 TRIP: COMMUNICATIONS FAULT WITH SLOT 4
10152 N12:3/4 52 TRIP_CommFlt_Slot5 TRIP: COMMUNICATIONS FAULT WITH SLOT 5
10153 N12:3/5 53 TRIP_CommFlt_Slot6 TRIP: COMMUNICATIONS FAULT WITH SLOT 6
10154 N12:3/6 54 TRIP_CommFlt_Slot7 TRIP: COMMUNICATIONS FAULT WITH SLOT 7
