SECTION 4 - MODBUS RTU SLOT LIST
JOHNSON CONTROLS
99
4
Modbus DF1 Count Logix Tag Description
10198 N12:6/2 98 AI_5VOLTSUPPLY.ALL 5 VOLT SUPPLY VERY LOW
10199 N12:6/3 99 AI_5VOLTSUPPLY.AH 5 VOLT SUPPLY HIGH
10200 N12:6/4 100 AI_5VOLTSUPPLY.AHH 5 VOLT SUPPLY VERY HIGH
10201 N12:6/5 101 AI_IT160A.OOR PRIMARY MOTOR CURRENT OUT OF RANGE
10202 N12:6/6 102 AI_IT160A.AL PRIMARY MOTOR CURRENT LOW
10203 N12:6/7 103 AI_IT160A.ALL PRIMARY MOTOR CURRENT VERY LOW
10204 N12:6/8 104 AI_IT160A.AH PRIMARY MOTOR CURRENT HIGH
10205 N12:6/9 105 AI_IT160A.AHH PRIMARY MOTOR CURRENT VERY HIGH
10206 N12:6/10 106 AI_IT160B.OOR ECONOMIZER MOTOR CURRENT OUT OF RANGE
10207 N12:6/11 107 AI_IT160B.AL ECONOMIZER MOTOR CURRENT LOW
10208 N12:6/12 108 AI_IT160B.ALL ECONOMIZER MOTOR CURRENT VERY LOW
10209 N12:6/13 109 AI_IT160B.AH ECONOMIZER MOTOR CURRENT HIGH
10210 N12:6/14 110 AI_IT160B.AHH ECONOMIZER MOTOR CURRENT VERY HIGH
10211 N12:6/15 111 AI_LE114.OOR SUBCOOLER LEVEL SENSOR OUT OF RANGE
10212 N12:7/0 112 AI_LE114.AL SUBCOOLER LEVEL SENSOR LOW
10213 N12:7/1 113 AI_LE114.ALL SUBCOOLER LEVEL SENSOR VERY LOW
10214 N12:7/2 114 AI_LE114.AH SUBCOOLER LEVEL SENSOR HIGH
10215 N12:7/3 115 AI_LE114.AHH SUBCOOLER LEVEL SENSOR VERY HIGH
10216 N12:7/4 116 AI_LE116.OOR ECONOMIZER LEVEL SENSOR OUT OF RANGE
10217 N12:7/5 117 AI_LE116.AL ECONOMIZER LEVEL SENSOR LOW
10218 N12:7/6 118 AI_LE116.ALL ECONOMIZER LEVEL SENSOR VERY LOW
10219 N12:7/7 119 AI_LE116.AH ECONOMIZER LEVEL SENSOR HIGH
10220 N12:7/8 120 AI_LE116.AHH ECONOMIZER LEVEL SENSOR VERY HIGH
10221 N12:7/9 121 AI_PE111.OOR EVAPORATOR PRESSURE OUT OF RANGE
10222 N12:7/10 122 AI_PE111.AL EVAPORATOR PRESSURE LOW
10223 N12:7/11 123 AI_PE111.ALL EVAPORATOR PRESSURE VERY LOW
10224 N12:7/12 124 AI_PE111.AH EVAPORATOR PRESSURE HIGH
10225 N12:7/13 125 AI_PE111.AHH EVAPORATOR PRESSURE VERY HIGH
10226 N12:7/14 126 AI_PE113.OOR CONDENSER PRESSURE OUT OF RANGE
10227 N12:7/15 127 AI_PE113.AL CONDENSER PRESSURE LOW
10228 N12:8/0 128 AI_PE113.ALL CONDENSER PRESSURE VERY LOW
10229 N12:8/1 129 AI_PE113.AH CONDENSER PRESSURE HIGH
10230 N12:8/2 130 AI_PE113.AHH CONDENSER PRESSURE VERY HIGH
10231 N12:8/3 131 AI_PE116.OOR ECONOMIZER PRESSURE OUT OF RANGE
10232 N12:8/4 132 AI_PE116.AL ECONOMIZER PRESSURE LOW
10233 N12:8/5 133 AI_PE116.ALL ECONOMIZER PRESSURE VERY LOW
10234 N12:8/6 134 AI_PE116.AH ECONOMIZER PRESSURE HIGH
10235 N12:8/7 135 AI_PE116.AHH ECONOMIZER PRESSURE VERY HIGH
10236 N12:8/8 136 AI_PE140.OOR OIL SUMP PRESSURE OUT OF RANGE
10237 N12:8/9 137 AI_PE140.AL OIL SUMP PRESSURE LOW
10238 N12:8/10 138 AI_PE140.ALL OIL SUMP PRESSURE VERY LOW
10239 N12:8/11 139 AI_PE140.AH OIL SUMP PRESSURE HIGH
10240 N12:8/12 140 AI_PE140.AHH OIL SUMP PRESSURE VERY HIGH
10241 N12:8/13 141 AI_PE141A.OOR PRIMARY OIL PUMP PRESSURE OUT OF RANGE
10242 N12:8/14 142 AI_PE141A.AL PRIMARY OIL PUMP PRESSURE LOW
