95
4.4.3. The marks of the exterior and
interior gears of the lubricating oil
pump should be on the visible side
when being assembled into the
pump body.
4.4.4. The new weather seal should be put
inside the oil pump cover groove.
5. Disintegrating and assembling of oil seal
5.1. Configuration diagram
Mark
※:Non-reusable part
Unit: N*m/kg*cm/Ft_Lb
