3ņ31
[V] Setting the EBL1 bearing fix mode (EBL1 Bearing FIX)
While this function is set to ANGLE , an EBL is fixed to the preset bearing. For example, if the true
bearing 020q is preset, the EBL is fixed to the true bearing 020q even when the own ship turns.
While the function is set to SCREEN , the EBL is fixed on the radar display.
Procedure 1 Press [RADAR MENU] key.
Press [3] key
Press [1] key.
The EBL1 Setting Menu will appear.
2 Press [3] key.
The setting of EBL1 Bearing Fix will be
switched between ANGLE and SCREEN .
ANGLE : EBL1 bearing is fixed to the preset
value.
SCREEN : EBL1 bearing is fixed on the radar
display.
[VI] Setting the EBL2 bearing fix mode (EBL2 Bearing Fix)
Procedure 1 Press [RADAR MENU] key.
Press [3] key.
Press [2] key.
The EBL2 Setting Menu will appear.
Subsequently, set the EBL2 bearing fix mode performing the same operation as explained in
[V].
Note: The course data is required for activating this function.
