3-46
3.4 General Radar Operation
y
y y
3
3.4.23 Displaying GPS Reception Status (GPS Status)
The reception status of GPS(GPS/DGPS/WAAS) which is connected to radar processor unit is
displayed.
This setting is enabled when a JRC’S GPS/DGPS/WAAS is connected to the GPS connector of
processor unit.
Procedures 1. Press the [RADAR MENU] key twice, and then perform the following
menu open procedure to open the GPS Status window.
4. NAV equipment Setting
→ 4. GPS Status
2. After check of the GPS status, press [0] key to close the GPS status
window.
This window cannot be opened in the transmission state.
To Next Page
