11-8
yyy
yyyy
yyyy
11
11.8 PROCESSOR UNIT (NDC-1477)
(1) Structure Desk Top Type (Horizontal putting and length putting using
combined)
(2) Dimensions Height 170 mm × Width 300 mm × Depth 320 mm
(3) Mass Approx. Below 10 kg
(4) Tune Method AUTO/MANUAL (Bar-graph indicate)
(5) STC (SEA) AUTO/MANUAL
(6) FTC (RAIN) AUTO/MANUAL
(7) Radar Interference Rejection Built-in (The effect can be adjusted by three stages.)
(8) Scan Correlation Function1/2/3, 2 Peak Hold Processing1/2
Automatic change of processing method. (Target range
synchronize/Clutter synchronize)
(9) Bearing Marker 360 ° in 1 ° digit.
Relative motion: Fixation
True motion: Rewrite at a position correct in every
scan.
(10) Heading Line Electronic (Stern Line can be displayed.)
(11) Radar Alarm Invasion, Secession, OFF can be selected.
With buzzer sound.(Possible to output to external buzzer. )
Ring.
Automatically acquisition by target tracking described in
Section “TARGET TRACKING”.
(12) Off Center Within 66 % of the radius of any range. (Except 96 NM)
Can be operated in all mode in relative motion.
Trail is succeed at Off Center mode.
(13) True motion Unit Built-in (Except 96 NM)
(14) True motion reset position 66 % of radius of any range.
Possible to manual reset.
(15) Twice zoom The zoom center is 66 % radius of any range. (Except 0.125
NM)
