JRC JMA-5912-6 - Using Card; Operate File on the Card (File Manager)

3-102
3.11 Using Card
y
y y
3
3.11 USING CARD
This radar has two card slots. Inserting a flash memory card (option) into a card slot, you can save
the following contents, saved in the process unit, in the card or can load data from the card to the
process unit.
• Track of own ship : 7000 points maximum
• Track of other ship : 20 target×1500 points (the Target Tracking unit, or AIS unit
option is necessary)
• Mark Line : 2000 points maximum (20000 items when the plotter unit
option is connected)
• Waypoint : 999 points maximum (the plotter unit option is necessary)
• Route : 10 routes maximum (the plotter unit option is necessary)
These pieces of information can be saved in a flash memory card as a file. The internal capacity is
as large as only a file. An internally created file can be saved until the flash memory card is full.
3.11.1 Operate File on the Card (File Manager)
Procedures 1 Insert a flash memory card into the card slot.
Flash memory card (option) is necessary.
For the insertion and removal of the card, see HOW TO INSERT AND REMOVE A
CARD in the appendix.
2 Press the [STBY] key.
The transmission standby state is activated.
3 Press the [RADAR MENU] key twice.
4 Press the [1] key.
The File Manager window will appear.
The window will not be open when the system is in the transmission state.
