Page #419 background imageLoading...
Page #419 background image
11-16
yyy
yyyy
yyyy
11
11.16 AVAILABLE OUTPUT SIGNAL
(1) Slave video Radar video: TIY, VD, BP (2048 p), BZ (Terminal board TB4302)
(2) Navigation information Send capability Port: .NAV1, NAV2, GPS port at terminal board TB4303.
NMEA Connecter at rear of the process unit (D-Sub 9 PIN). IEC61162-1/2
Radar system data: RSD
Own ship data: OSD
Tracking target data: TTM, TLL, TTD, TLB, JRC-ARPA
AIS target data: TTM, TLL, TTD, TLB
Alarm: ALR
Auto pilot: APB
Bearing of destination: BOD
Latitude/Longitude data: GGA, GLL, RMC
Waypoint data: RMB, BWC
COG/SOG data: VTG
Cross track error: XTE
Heading data: HDT, THS
(3) External alarm Default setting: normally closed contact
Maximum current: 200 mA
(SYSALM, ARPAALM port at terminal board TB4303).
(4) External monitor Multi scan monitor, Analog RGB, HD15 pin Connector
11.17 STANDARD CONFIGURATION
(1) Scanner 1
(2) Display unit 1 (Process unit, LCD unit, Operation unit)
(3) Equipment cable 10/25 kW
Standard:20 m
30 kW
Display unit to junction box Standard: 10 m
Junction box to scanner Standard: 20 m
(4) Equipment reserve parts 1
(5) Instruction manual 1 (Japanese or English)
