7-15
[II] Sector Blank Area Creation (Make Sectors 1, 2, and 3)
Procedures 1. Transmit the radar.
2. Open the Serviceman Menu.
3. Open the Sector Blank menu by performing the following menu
operation.
2. Installation Menu
→ 3. Sector Blank
4. Press numeric keys corresponding to the desired sector creation
Make Sector 1 , 2 , or 3 .
The selected sector blank will be made.
5. Set the starting bearing of the sector blank by operating the [EBL] dial,
and press the [ENT] key.
6. Set the ending azimuth of the sector blank by operating the [EBL] dial,
and press the [ENT] key.
7.2.3 TNI Blank Setting (TNI Blank)
Set a sector and stop tuning operation in the bearing.
If a structure such as the mast is close to the radar antenna, automatic tuning operation may become
unstable. In this case, set a TNI blank in the direction of the structure in order to stabilize the tuning
operation.
Only one TNI blank sector can be created. The TNI blank function operates in the relative bearing with the
bow as the benchmark.
[I] TNI Blank Function On/Off (Sector)
Procedures 1. Open the Serviceman Menu.
2. Open the TNI Blank menu by performing the following menu
operation.
2. Installation Menu
→ 9. Next
→ 2. TNI Blank
3. Select the item 1. TNI Blank in the menu, and turn on or off the TNI
blank function.
On : The TNI blank function is operated.
Off : The TNI blank function is stopped.
To Next Page
