11.12 OPERATION UNIT (NCE-5171)
(1) Structure Structure of operation unit is separate from processor unit.
Desk-Top type
Correspond Flush mount
(2) Switch
GAIN/PL: Adjust the reception gain. (Transmit pulse width
can be changed by PUSH-SW.)
AUTO-SEA: Sea clutter suppression.
(AUTO/MANU can be changed by PUSH-SW.)
AUTO-RAIN: Rain clutter suppression.
(AUTO/MANU can be changed by PUSH-SW.)
MULTI: Change the setting. (Adjustment item can be
changed by PUSH-SW)
EBL (Electric Bearing Line): Rotate the bearing of the EBL (Floating EBL
ON/OFF can be changed by PUSH-SW.)
VRM (Variable Range Marker): Change the VRM range.
(3) Operation switch
Trackball: Move the cursor mark.
STBY/OFF (Standby/Power off): Stop transmit, Power off.
TX/OFF (Transmit Start/Power Off): Start transmit, Power off
PANEL (Brightness of Keyboard Adjustment): Brightness of keyboard switch adjust.
ALARM ACK (Alarm Acknowledge): Acknowledge and stop alarm.
EBL1: Selection display and non-display of EBL1.
EBL2: Selection display and non-display of EBL2.
VRM1: Selection display and non-display of VRM1.
VRM2: Selection display and non-display of VRM2.
RANGE+ (Increase Display Range): Increase display range.
RANGE- (Decrease Display Range): Decrease display range.
ACQ (Acquisition): Target acquisition
TGT DATA (Numeric Display): Numeric display of tracking target.
TGT CNCL (Cancel of Selection): Release of selection of tracking target.
MOB (Marker): Turning on and release marker.
ENT (Enter): Left side button of trackball.
CLR/INFO (Clear/Information): Right side of trackball.
MAP (Display Mode): Selection display and non-display of MAP(NAV
LINE, etc...).
Selection of Rader, Synthesis and Plotter mode.
AZI MODE (Display Azimuth Mode): Selection of North-up, Course-Up, Head-Up.
TM/RM (True/Relative Motion): Selection true motion, relative motion.
RR/HL (Range Ring/Heading line): Selection display and non-display of fixed ring
and heading line.
OFF CENT(Off Center): Off center operation
AZ (Automatic Acquisition/Activate zone): Setting and release of acquisition/activation zone.
VECT T/R (True/Relative Motion Vector): Selection of true motion and relative motion of
vector.
TRAILS: Switching trails display time.
DAY/NIGHT: Selection of screen arrangement of color.
FUNC (Function): Selection of signal processing.
USER KEY1: User assignment key1.
USER KEY2: User assignment key2.
RADAR MENU: Rader menu.
MARK: Selection display and non-display of mark.
TT MENU: Target tracking menu.
