11-17
11.18 EQUIPMENT DISTANCE BETWEEN
OTHER INSTRUMENTS
Maximum Standard
(1) LCD monitor to processor unit 5 m 5 m
(2) Keyboard unit to processor unit 5 m 5 m
(3) Scanner to display unit (10/25 kW) 65 m 20 m
(4) Scanner to junction box (30 kW) 50 m
*1
20 m
(5) Junction box to display unit (30 kW) 30 m
*1
10 m
*1 Total distance between scanner and display unit must be 65 m or less.
11.19 OTHERS (OPTION)
• Coast line ROM card
• Memory card
• Interswitch unit (NQE-3141)
• Rectifier unit (NBA-5111)
