11.9 TARGET TRACKING FUNCTION
Radar mode, synthesis mode
(1) Available range scale All range
(2) Acquisition MANUAL/AUTO(by two automatic
acquisition/activation zone)
Acquisition range: 0.1 to 32NM (Available all range scale)
(3) Tracking 100 target
Tracking range: 0 to 32NM (Available all range scale)
(4) Display Tracking data: 4 at the same time. (Can be scroll.)
Naming function: Possible to name by the alphabet up to 8
characters to each target.
The range, bearing, CPA, TCPA, true course, true speed, BCR,
BCT of target can be displayed. (When naming is displayed,
BCR/BCT can’t be displayed.) Vector display: True/Relative Past
position
(5) Alarm Automatic acquisition/activation zone
Danger ship: Depends on CPA/TCPA setting.
(6) Trial Maneuver Input parameter: Course, Speed, Vector time, Time to Maneuver,
Reach, Turn Radius, Acceleration, Deceleration
Synthesis mode
(7) Another ship track 20 targets. 1500 point per one target can be displayed. (Own ship
track and marks are another.)
Display color: 7 colors (The display color of each target can be
set.) (The display color of all targets can be set by the batch. In
this case, the display color is one color.)
Interval of save: 3/5/10/30 sec, 1/3/5/10/30/60 min, 1/3/5/10 NM
Possible to storage in memory card (Option).
