3-95
3.9.2 Function Setting Menu Items (User Function Setting)
The function setting menu has the items below.
Page 1
Page 2
Page 3
Page 4
Page 5
1. Gain Offset Gain correction Correction value setting
2. PRF Pulse repetition frequency Normal / Economy / High Power
3. Small Buoy Detection Small target detection mode Off / On
4. Fishnet Detection Fishnet detection mode Off / On
5. Antenna Height Antenna height Default / -5m / 5-10m / 10-20m / 20m-
1. Trails Interval Radar trails length Off / 15sec / ････
2. Trails Mode Radar trails mode True / Relative
3. Trails Reference Level Radar trails plotting threshold Level1-4
4. Trails Reduction Thinning of radar trails Off / Level1-3
5. Time / All Combine Superimpose-display of time radar
trails and continuous radar trails Off / On
6. Trails Process Radar trails video process Off / On
7. Max Interval Maximum time for radar trails display Short / Middle / Long / Super Long
1. Video Latitude Dynamic range of radar video Narrow / Normal / Wide / Super Wide
2. Video Noise Rejection Radar video noise rejection Off / Level1 / Level2
3. AUTO Dynamic Range Automatic dynamic range control Off / On
4. Process Switch Radar video process switching Off / Range FIX / AUTO
5. 2nd Process Mode Second video process mode PROC Off / 3Scan CORREL / ････
6. Process Switch Range Video process switching range Range setting
7. Fast Target Detection Fast moving target detection Off / On
1. Pulse Length 0.75NM Standard pulse length of 0.75 NM range SP1 / MP1
2. Pulse Length 1.5NM Standard pulse length of 1.5 NM range SP1 / MP1 / MP2 / MP3
3. Pulse Length 3 / 4NM Standard pulse length of 3 NM range MP1 / MP2 / MP3 / LP1
4. Pulse Length 6 / 8NM Standard pulse length of 6 NM range MP1 / MP2 / MP3 / LP1 / LP2
5. Pulse Length 12NM Standard pulse length of 12 NM range MP1 / MP2 / MP3 / LP1 / LP2
6. Pulse Length 16NM Standard pulse length of 16 NM range MP1 / MP2 / MP3 / LP1 / LP2
1. Mode Name of the mode to be used Coast / Deepsea / ････
2. IR Radar interference rejection Off / Low / Middle / High
3. Process Video process PROC Off / 3Scan CORREL / ････
4. Target Enhance Target enhance Off / Level1 / Level2 / Level3
5. AUTO STC/FTC Automatic clutter suppression Off / AUTO Sea / AUTO Sea/Rain
6. Save Present State Saving of the present state
