8-27
z When replacing the LCD monitor, which is easily
broken by a little impact, handle it carefully and do not
hit any article against it or put it on a hard article.
8.4.4 Replacement of LCD Monitor
Caution:
Replacement of LCL Monitor must be made by specialized service personnel.
For details, refer to Service Manual.
(1) Disconnect the cables from the connectors “VIDEO” and “AUX” on the rear of the processor.
(2) Softly place the LCD monitor on a desk covered with a soft cloth.
(3) Attach a new LCD monitor in the reverse sequence as described above.
Attention
To Next Page
