JUKI MO-6904S - Joining the sub-table (only for the long table type)

– 10 –
❶
❸
❷
❹
3-11.Joiningthesub-table(onlyforthelongtabletype)
Butting the sub-table and the main-body table with no clearance provided between them, x clips
❶
(at three
locations) with thumbscrews
❷
. Lock casters
❸
(at four locations) to secure the sub-table.
Sub-table
Main-bodytable
CAUTION
:
Connectthesub-tabletothemain-bodytabletakingcarenottoallowyourngerscaughtbetween
them.
A difference in height between the top face of the main-body table and that of the sub-table may be observed
on some installation site.
If such a difference is observed, adjust so that the tables are same in height with spacers
❹
for adjusting the
height of the clips. (Three spacers are supplied.)
・
If the sub-table is lower than the main-body table :
Add the supplied spacer(s) appropriately.
・
If the sub-table is higher than the main-body table :
Remove spacer
❹
and change with a thinner one.
