❶
switch: Usedforreturningthesettingtotheinitialvalue.
❷
switch: Usedforchangingthecontentsofsetting.
When this switch is pressed, changeable positions ash on and off.
By pressing the switch, ashing position shifts in the left direction.
Starting the machine is prohibited while the switch lamp is ashing on and off (setting mode).
❸
switch: Usedforchangingthecontentsofsetting.
By pressing the switch, ashing position shifts in the right direction.
❹
switch: Usedforchangingthecontentsoftheselecteddisplay(ashingsection).
When this switch is pressed, the set value is decreased.
❺
switch: Usedforchangingthecontentsoftheselecteddisplay(ashingsection).
When this switch is pressed, the set value is increased.
❻
switch: Usedfordeterminingthecontentsofsetting.
When this switch is pressed, ashing stops and the contents of setting are determined.
The machine enters the sewing mode under which it can start. When the material to be sewn is already
placed on the machine under the Automatic mode, E333 will appear on the operation panel. In this case,
the machine is unable to enter the sewing mode. If the curve sensor is set effective, the same phenome-
non occurs when the material is already placed on the machine (E334). If E334 is displayed, check rstly
the neighboring area of the sensor whether the material has been placed on the machine. (The same
phenomenon occurs when dust settles on the sensor. Check the neighboring area of the sensor for
dust.) The operation level can be changed by keeping this switch held pressed for three seconds while
the switch light is ashing on and off.
5-2.Explanationoftheoperationpanel
Ifthepowertothemachineisturnedoffbeforehavingtakentheaforementionedprocedure,thedata
changedwillnotbestoredinmemory.
Ⓐ
Setitemindication: Abbreviationofthenameofthesetitemselectedisdisplayed.
Ⓑ
Setcontentsindication: Contentofthesetitemselectedisdisplayed.
❷
Ⓐ
Ⓑ
❸ ❹ ❺❶ ❻
