JUKI MO-6904S - Installing the dust collector

– 4 –
3-3.Installingthedustcollector
1) Plug the lings blowing hose
❷
and the chain-
off thread blowing hose
❸
into the dust collec-
tion box
❶
.
2) Install lter
❹
so that it completely covers the
top of the box.
Install the dust collection box
❶
to the rear of the
main unit, as shown in the gure.
(Conguration position differs depending upon speci-
cation.)
Shorttabletype
Longtabletype
Whendumpingdustfromthedustcollec-
tionbox,alsocleanuplter
❹
.
Conrmthatthehosemountingbracket
❺
iscompletelytightened(thesameforother
mountinghardware).Notethatthenoise
mufer
❻
is optional.
CAUTION :
If the dust collector is not securely in-
stalled,blown-outdustorlintcangetin
eyes,resultinginpersonalinjury.
❶
❷
❸
❹
❺
❶
❺
❻
