JUKI MO-6904S - Installing the stacker cloth guide

– 6 –
❶
❸
❷
❹
❶
3-5.Installingthestackerclothguide
Installing stacker cloth guide
❶
on the guide base
with hand screw
❷
and washer
❸
.
Adjust the orientation of the cloth guide according to
the clamping position at the stacker unit
❹
.
Materialfeedingdirection
