– 12 –
1) Refer to "18. FUNCTION SETTING SWITCH" in
the Instruction Manual for the CP-180, and call
the function setting No. 95.
2) The type of machine head can be selected by
pressing switch .
Select the type of the machine head according to
the table given below.
• CP-180
3) After selecting the type of machine head, by
pressing switch , the step proceeds to 96 or
94, and the display automatically initializes to the
contents of the setting corresponding with the type
of machine head.
Type Marking
PLC-2710-7
,
2760-7 P27d
PLC-2710, 2760, 2765 PL27
PLC-2760L PL2L
To Next Page
