– 38 –
Needle lifting switch
If this switch is pressed, the machine will travel from the needle-down stop position to the needle-up
stop position.
When raising the machine head which has been tilted, do not hold the operation switch to raise
it.
2P switch
If this switch is pressed, the stitch length is
changed over to that of the scale on the 2P feed
adjusting dial. (Lamp in the button is lit up.)
Be sure to make the number of 2P feed
adjusting dial less than that of the stan-
dard feed adjusting dial.
Example
・
Standard feed adjusting dial scale : 9
・
2P feed adjusting dial scale : 6
・
If this switch is pressed, stitch length is
changed over from 9 to 6.
OFF ON
・
If this switch is pressed again, stitch length
returns from 6 to 9.
Needle thread tension changeover switch
When the switch is pressed, the double tension function is selected to increase the needle thread ten-
sion. (The lamp above the switch is lit up.)
This is not used for the PLC-2710-7 and -2760-7.
