JUKI SC-922 Engineer's Manual

– 22 –
14 Sewing counter Counting function of sewing (number of completion 0 to 2 U 35
of press)
0 :Sewing counter function is not operative
1 :Sewing counter function is operative
(Every time thread trimming is performed)
2 :With the sewing counting switch input function
15 Thread wiping Thread wiping operation after thread trimming is 0/1 U
function after specified.
thread trimming 0 :Thread wiping is not carried out after thread
trimming
1 :Thread wiping is carried out after thread trimming
21 Function of Function of needle up/down compensating switch on 0 to 2 U 35
neutral the operation panel can be changed.
presser lifting 0 : Function of neutral automatic presser lifting is not
1 :Function of neutral automatic presser lifting is
operative.
2 :Neutral automatic presser lifting is valid and the
alternate motion can be performed by
depressing the panel backward.
(This function is disabled when No. 93 Needle
up/down switch additional function setting is “2.”)
22 Needle up/down Function of the needle up/down correction switch is 0/1 U 35
correction switch changed over.
changeover 0 :Needle up/down compensation
function 1 :One stitch compensation
24 Number of Sewing speed set of end reverse feed stitching. 100 to 3000 S
rotation of end Set point sews it at the speed that I set with No. 8 (sti/min)
reverse feed in the case of 100.
stitching
25 Thread trimming Thread trimming operation after moving the needle 0/1 U
operation after away from its upper or lower position by turning the
turning the handwheel by hand is specified.
handwheel by 0 :Thread trimming operation is carried out after
hand turning the handwheel by hand
1 :Thread trimming operation is not carried out
after turning the handwheel by hand.
26 Function selection Change the function of the reverse feed stitching 0 to 4 S
of reverse feed switch.
stitching switch 0 :It is always a backstitch function
1 :It is Needle up/down switch function double
touch at the time of the stop
2 :It is Needle up/down switch function at the time
of the stop
3 :It is Needle lifting switch function at the time of
the stop
4 :It is reverse needle lifting switch function at
the time of the stop
29 Initial time This function sets the suction time of initial motion 50 to 500 U 35
of back-tack of back-tack solenoid. (ms)
30 Function of Function of reverse feed stitching on the way 0/1 U 36
reverse feed 0 :Function of reverse stitching on the way is not
stitching on operative.
the way 1 :Function of reverse feed stitching on the way
is operative.
31 Number of stitches Number of stitches of reverse feed stitching on the 0 to 19 U 36
of reverse feed way. (Stitches)
stitching on the
way
32 Effective condition Effective condition of reverse feed stitching on the 0/1 U 36
of reverse feed way
stitching on the 0 :Function is not operative when sewing machine
way when the stops.
sewing machine 1 : Function is operative when the sewing machine
is stopping stops.
(Start level ; U : User’s mode, S : Service mode)
No. Item Description Setting range Setting level
4
1
1
5
1
0
1
2
0
2
2
0
4
2
0
0
1
5
2
1
6
2
0
9
2
0
5
2
0
3
0
Indication of
function setting
Ref.
page
∗ Do not change the set values with asterisk (∗) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
1
3
4
2
3
0
