– 23 –
33 Thread trimming Thread trimming function by reverse feed stitching 0/1 U 36
function by on the way
reverse feed 0 :Automatic thread trimming function after
stitching on the completion of reverse feed stitching on the
way way is not operative.
1 :Automatic thread trimming after completion of
reverse feed stitching on the way is performed.
34
End reverse When there is less length that I sewed than the
0 to 19 S
feed stitching number of the set needles, I do not perform end
(Stitches)
ineffective backstitch.
Number of
stitches
35 Number of Lowest speed by pedal (The MAX value differs by 150 to MAX U
rotation at a machine head.) (sti/min)
low speed
36 Number of Thread trimming speed (The MAX value differs by 100 to MAX U
rotation of machine head.) (sti/min)
thread trimming
37 Number of Sewing speed at the start of sewing (soft-start) 100 to MAX U 31
rotation of (The MAX value differs by machine head.) (sti/min)
soft-start
38 One-shot speed One-shot speed (The MAX. value depends on the 150 to MAX U 36
number of rotation of the sewing machine head.) (sti/min)
39
Pedal stroke at the
Position where the sewing machine starts rotating 10 to 50 U
start of rotation from pedal neutral position (0.1mm)
(Pedal stroke)
40 Low speed Position where the sewing machine starts accelerating 10 to 100 U
section of from pedal neutral position (0.1mm)
pedal (Pedal stroke)
41 Starting position Position where the cloth presser starts lifting from -60 to -10 U
of lifting presser pedal neutral position (0.1mm)
foot by pedal (Pedal stroke)
42 Starting position Starting position of lowering presser foot 8 to 50 U
of lowering Stroke from the neutral position (0.1mm)
presser foot
43 Pedal stroke 2 Position 2 where the thread trimming starts from -60 to -10 U
for starting pedal neutral position (When the function of lifting (0.1mm)
thread trimming presser foot by pedal is provided.)
(Pedal stroke)
44 Pedal stroke for Position where the sewing machine reaches its 10 to 150 U
reaching the highest sewing speed from pedal neutral position (0.1mm)
maximum number
(Pedal stroke)
of rotation
45 Compensation Compensation value of the pedal sensor -15 to 15 U
of neutral point (0.1mm)
of the pedal
46 Presser rising Select the presser motion after turning on the power. 0/1 S
after turning 0 :Not rising
on the power 1 :Rising
47 Holding time of Limitation time of waiting for lifting solenoid type 10 to 600 U 37
lifting auto-lifter auto-lifter device (S)
48 Pedal stroke 1 Position where thread trimming starts from pedal -60 to -10 U
for starting neutral position (Standard pedal) (Pedal stroke) (0.1mm)
thread trimming
49 Lowering time Lowering time of presser foot after the pedal has 0 to 500 U 39
of presser foot been depressed. (10ms)
(Start of rotation of the sewing machine is delayed
during this time.)
