– 34 –
Function code
Abbreviation
Function item Remarks
0 noP No function (Standard setting)
1TrM Thread trimming output Output of thread trimming signal
2 WiP Thread wiper output Output of thread wiper signal
3TLThread release output Output of thread release signal
4FLPresser lifter output Output of presser lifting signal
5bTReverse feed stitching output Output of reverse feed stitching signal
6 EbT EBT cancel monitor output
State of one time cancel of reverse feed stitching at end function is output.
7 SEbT
Reverse feed stitching at start/end cancel monitor output
State of cancel of reverse feed stitching at start/end is output.
8 AUbT
Sewing start/end cancellation/addition monitor output State of cancel or addition of automatic reverse feed stitching is
output.
9 SSTA Sewing machine stop state output Sewing machine stop state is output.
10 CooL Needle cooler output Output for needle cooler
11 bUZ Buzzer output It is outputwhen the bobbin counter set value has been exceeded, an
error has occurred or the bobbin thread remaining amount is detected.
12 LSWo Revolution command output Revolution demanding command state is output.
13 vErT Alternate up/down amount conversion Alternate up/down amount conversion signal is output.
(monitor) output
14 2PiT 2-pitch output 2-pitch signal is output.
15 bCGo Bobbin replacement monitor output
Sewing machine start-up prohibition state during bobbin replacement is output.
16 TC Thread grasping enabled state monitor output Thread grasping enabled state is output.
17 CAbT S/EBT 1-time cancellation monitor output One-time cancellation state of the reverse feed stitching at the be-
ginning or end sewing is output.
18 SToP Stop state monitor output Sewing machine operation prohibition state is output.
19 AEbo Remaining check device air blow output Air blow output when using the remaining check device
20 UdET Up position output Up state output
21 ddET Down position output Down state output
Output function list
Input function setting connectors
Pin No. Display No. Initial value of function setting
4 i01 Machine head switch 1 input
5 i02 Machine head switch 2 input
6 i03 Machine head switch 3 input
7 i04 Machine head switch 4 input
8 i05 Machine head switch 5 input
9 i06 Machine head switch 6 input
10 i07 Machine head switch 7 input
11 i08 Machine head switch 8 input
15 i09 Option 1 input
16 i10 Option 2 input
17 i11 Option 3 input
18 i12 Option 4 input
19 i13 Option 5 input
20 i14 Option 6 input
21 i15 Option 7 input
22 i16 Option 8 input
4 i17 Option 9 input
5 i18 Option 10 input
6 i19 Option 11 input
7 i20 Option 12 input
8 i21 Option 13 input
9 i22 Option 14 input
10 i23 Option 15 input
11 i24 Option 16 input
7 i25
TSW (thread trimming switch input)
11 i26 LSSW (low speed switch)
9 i27 HSSW (low speed switch)
5 i28 FL (presser lifter switch input)
2 i29 SFSW (safety switch input)
1 i30 noP (no function is assigned)
4 i31 FL (presser lifter switch input)
5 i32
bT (reverse feed stitching switch input)
Connector
No.
CN44
CN58
CN51
CN39
CN48
CN36
Output function setting connectors
Pin No. Display No. Initial value of function setting
15 o01 Machine head LED 1 output
16 o02 Machine head LED 2 output
17 o03 Machine head LED 3 output
18 o04 Machine head LED 4 output
19 o05 Machine head LED 5 output
20 o06 Machine head LED 6 output
21 o07 Machine head LED 7 output
22 o08 Machine head LED 8 output
11 o09 Option 1 output
12 o10 Option 2 output
13 o11 Option 3 output
14 o12 Option 4 output
15 o13 Option 5 output
16 o14 Option 6 output
17 o15 Option 7 output
18 o16 Option 8 output
19 o17 Option 9 output
20 o18 Option 10 output
21 o19 Option 11 output
22 o20 Option 12 output
23 o21 Option 13 output
24 o22 Option 14 output
25 o23 Option 15 output
26 o24 Option 16 output
15 o25 Option 17 output
16 o26 Option 18 output
17 o27 Option 19 output
18 o28 Option 20 output
19 o29 Option 21 output
20 o30 Option 22 output
21 o31 Option 23 output
22 o32 Option 24 output
Connector
No.
CN44
CN59
CN51
