– 33 –
Input function list
Function item Remarks
0 noP No function (Standard setting)
1HSNeedle up/down compensating stitching Every time the switch is pressed, normal feed stitching by half stitch
is performed. (Same operation as that of up / down compensating
stitching switch on the panel.)
2 bHS Back compensating stitching Reverse feed stitching is performed at low speed while the switch is
held pressing. (It is effective only when a constant-dimension sew-
ing is selected.)
3 EbT Function of canceling once reverse feed By depressing the back part of the pedal after pressing the
stitching at the end of sewing switch, operation of reverse feed stitching is canceled once.
4 TSW Thread trimming function This function is actuated as the thread trimming switch.
5 FL Presser foot lifting function This function is actuated as the foot lifter switch.
6 oHS One stitch compensating stitching Every time the switch is pressed, one stitch stitching operation is
executed.
7 SEbT Function of cancel of reverse feed stitching at By operating the optional switch, ineffective/effective can be
start/end alternately changed over.
8 PnFL Presser lifting function when pedal is Every time the switch is pressed, the function whether automatically
neutral lifting the presser foot when the pedal is neutral or not can be se-
l lected.
9EdMaterial edge sensor input This function works as the input signal of material edge sensor.
10 LinH Function of prohibiting depressing front part Rotation by pedal is prohibited.
of pedal
11 TinH Function of prohibiting thread trimming output Output of thread trimming is prohibited.
12 LSSW Low speed command input This function works as low speed switch for standing sewing ma-
chine.
13 HSSW High speed command input This function works as high speed switch for standing sewing ma-
chine.
14 USW Needle lifting function UP stop motion is performed when switch is pressed during DOWN
stop.
15 bT Reverse feed stitching switch input Reverse feed stitching is output as long as the switch is held pressed.
16 SoFT Soft start switch input The speed of stitch is limited to the predetermined soft-start speed
as long as the switch is held pressed.
17 oSSW One-shot speed command switch input This function works as one-shot speed command as long as the
switch is pressed.
18 bKoS Backward one-shot speed command switch Reverse feed stitching is performed in accordance with the one-shot
input speed command as long as the switch is held pressed.
19 SFSW Safety switch input Rotation is prohibited.
20 MES Thread trimming safety switch input It operates as an input signal of the thread trimmer safety switch.
21 AUbT Automatic reverse feed stitching cacellation/ Every time the switch is pressed, reverse feed stitching at sewing
addition switch start or reverse feed stitching at sewing end is cancelled or added.
22 CUnT Sewing counter input Every time the switch is pressed, the sewing counter value is in-
creased.
23 rSW Reverse-rotation needle-up function When the switch is pressed while the sewing machine is at rest with
its needle up, the machine rotates in reverse direction and brakes to
stop at the specified angle. When the switch is pressed while the
sewing machine is at rest with its needle down, the machine rotates
in normal direction and brakes to stop at the specified angle.
24 vErT Alternate up/down amount conversion panel
Alternate up/down conversion output is inverted every time the switch
switch input is pressed.
25 vSW Alternate up/down amount conversion knee Alternate up/down conversion is output as long as the switch is held
switch input pressed
26 2PiT 2-pitch alternate input 2-pitch output is inverted every time the switch is pressed
27 2PSW 2-pitch momentary switch input 2-pitch is output as long as the switch is held pressed
28 bbCG Bobbin replacement switch input Startup of the sewing machine is disabled when the switch is turned
ON for the first time. (Bobbin replacement) The presser foot is low-
ered and the normal operation is restored when the switch is turned
ON for the second time.
29 CGUd Center guide switch input Center guide output is inverted every time the switch is pressed.
30 TCSW Thread grasping switch input Thread clamp function is enabled while the switch is pressed.
31 ALFL Presser lifter alternate switch input Presser lifter output is inverted every time the switch is pressed.
32 CAbT S/EBT 1-time cancellation input Reverse feed stitching at the beginning or end of sewing, to be per-
formed after a press on the switch, is cancelled once.
33 SToP Stop switch input The sewing machine is stopped and the operation is prohibited as
long as the switch is held pressed.
34 bCGP Bobbin replacement P-switch input When the switch is turned ON for the first time, the sewing machine
stops with its needle up, then presser foot goes up and the start-up
of the sewing machine is disabled. (Bobbin replacement) The presser
foot is lowered and the normal operation is restored when the switch
is turned ON for the second time.
