– 61 –
Connector No. Pin No. Port input code Function
15 1 Machine head LED 1 output
16 2 Machine head LED 2 output
17 3 Machine head LED 3 output
18 4 Machine head LED 4 output
19 5 Machine head LED 5 output
20 6 Machine head LED 6 output
21 7 Machine head LED 7 output
22 8 Machine head LED 8 output
11 9 Optional 1 output
12 10 Optional 2 output
13 11 Optional 3 output
14 12 Optional 4 output
15 13 Optional 5 output
16 14 Optional 6 output
17 15 Optional 7 output
18 16 Optional 8 output
19 17 Optional 9 output
20 18 Optional 10 output
21 19 Optional 11 output
22 20 Optional 12 output
23 21 Optional 13 output
24 22 Optional 14 output
25 23 Optional 15 output
26 24 Optional 16 output
15 25 Optional 17 output
16 26 Optional 18 output
17 27 Optional 19 output
18 28 Optional 20 output
19 29 Optional 21 output
20 30 Optional 22 output
21 31 Optional 23 output
22 32 Optional 24 output
2) Output connector
This optional output can be connected to up to a +24 V solenoid valve, an output to a PLC, an LED for display, etc.
CN51
CN59
CN44
(Caution) 1. When the voltage output port mounted on the input/output connector is used, the current per
circuit should be 0.4 A or less.
2. An actuator of large counter electromotive force such as a magnet cannot be driven with this
output circuit. When an actuator such as a magnet is used, use the output of CN36.
