8 Configuration
Analog outputs 0utA ➔ Output 5 0ut5 ➔
Output 6 0ut6 ➔
Output 7 0ut7 ➔
Symbol Value/selection Description
Function
Fnct
(analog selector)
switched off
Function of the output
Type of signal
S iGn
0
1
2
3
Physical output signal
0—10V
2—10V
0—20mA
4—20mA
Range output
r0ut
0…101% Signal on going above/below range
101 = last output signal
Zero point
0Pnt
-1999…0…+9999 A physical output signal is assigned to the value range of an
output variable.
Ex-factory, the setting corresponds to an output level of
0 — 100% for controller outputs.
No changes of the ex-factory setting are required for
continous controllers with only one output.
Example (function as a transducer):
An analog output (0 — 20mA) is to be used to put out the
process value (value range 150 to 500 °C), that means:
150 to 500°C
0 — 20mA; Zero point: 150 / End value: 500
End value
End
-1999…
100
…+9999
Offset (setup) -1999…0…+9999 The offset is used to correct the output signal by a certain
amount upwards or downwards.
Examples:
Original Output
value Offset value
294.7 +0.3 295.0
295.3 - 0.3 295.0
Factory settings are shown bold.
H
If the output is a controller output, the controller
switches over to manual mode and produces the
output level defined in chapter “Controller Cntr”
under rOut.
Chapter 8.2 “Controller “Cntr””
H
Setting for controller outputs for cooling
With 3-state controllers, the following settings must
be predefined:
zero: 0 / end value: -100
Analog selector
0 no function 21 program run time in sec
1 analog input 1 22 residual program time in sec
2 analog input 2 23 segment run time in sec
3 process value 24 residual segment time in sec
4 present setpoint 25 timer run time for timer 1 in sec
5 ramp end value 26 timer run time for timer 2 in sec
6 program setpoint 27 residual run time for timer 1 in sec
7 math 1 28 residual run time for timer 2 in sec
8 math 2 29 present segment end value
9 setpoint 1 30 analog marker (Profibus)
10 setpoint 2 31 reserved
11 setpoint 3 32 reserved
12 setpoint 4 33 reserved
13 controller output level
14 controller output 1
15 controller output 2
